Key Features

25 – 300 watts suggested amplifier power range

JBL engineers designed the ES25C center-channel speaker to produce precise, exceptional sound from a receiver or amplifier capable of delivering up to 300 watts of power.--

Proprietary 5", PolyPlas dual transducers-

The ES25C's stiff, lightweight PolyPlas driver material, with a rubber surround, reproduce vocals with incredible accuracy, gives great bass response, creates a seamless surround field and minimizes distortion, even at high volumes. Together, the driver and surround give you an unmatched audio experience.-
Dual 3/4" tweeters-

The ES25C's tweeters deliver accurate, undistorted response, even when the volume is way up. The end result is a full, clear, tight reproduction of high and ultrahigh frequencies.-

Elliptical Oblate Spheroidal (EOS) waveguides-

The ES25C's proprietary EOS waveguide technology delivers precise imaging throughout your listening environment. You get ideally balanced music, crisp dialogue and smooth audio distribution. Every seat will be the best seat in your home theater.-

Three-way speaker configuration-

Three-way speaker design and quality drivers make for tight, precise bass and midrange reproduction. As a result, the ES25C offers a full range of frequencies and lifelike imaging.-

Straight-Line Signal Path (SSP) design-

The ideal path from input to components to transducers is a straight line. The ES25C takes that path. Its Straight-Line Signal Path™ (SSP) technology preserves the clarity, detail and dynamics of your favorite audio content.-

Computer-optimized, bass reflex port-

The ES25C's computer-optimized, bass-reflex port extends deep bass response. It also eliminates the unwanted turbulence that's usually associated with powerful speakers.-

Accurate frequency response-

The ES25C doesn't over-emphasize or under-emphasize any sounds. With a frequency response of 80Hz - 40kHz, it reproduces a true, full sound range from deep bass tones to ultrahigh frequencies.-

Magnetically shielded-

The ES25C produces great, sit-anywhere sound in your room. And you can put it anywhere, because it's magnetically shielded for safe placement near your TV or display.

Specifications-----------

Frequency response (–3dB)

80Hz – 40kHz

Max. recommended amplifier power*

150W

Power handling (continuous/peak)

75W/300W

Sensitivity (2.83V/1m)

90dB

Nominal impedance

8 ohms

Crossover frequencies

3kHz – 24dB/octave; 12kHz – 18dB/octave

Low-frequency transducer

Dual (5") PolyPlas™, shielded

High-frequency transducer

(3/4") titanium-laminated dome, shielded; EOS waveguide

Ultrahigh-frequency transducer

(3/4") polyester film, ring radiator, shielded; EOS waveguide

Dimensions with grille (H x W x D)

178mm x 476mm x 254mm

Weight per speaker

7.6kg

-

Key Features

Speaker Type

Center Speaker

Mounting

Floorstanding

Construction

3-Way

Outdoor/Indoor

Indoor

Technical Details

Peak Power Handling

300 W

Nominal Power

75 W

Frequency Responses

80 Hz - 40 kHz

Impedance

8 ohm

Sensitivity

90 dB

Subwoofer Power

75 watt

Magnetic Shielding

Magnetically Shielded

Connectivity

Wired

Design

Available Colors

Black

Cabinet Finish

Plastic

Woofer Material

Poly / Plastic

Dimension

Width

18.75 in.

Depth

10 in.

Woofer Size

5 in.

Tweeter Size

0.75 in.

Weight

16.7 lb
